AXS-500R500
AXS- 500R500 Vault
A plastic tier-rated handhole is a lightweight, corrosion-resistant access enclosure made from durable HDPE or engineered polymer materials, available in load ratings from Tier 8 through Tier 22 (up to 22,000 lbs). Designed for telecom, electrical, and fiber optic applications, it provides flexibility across a wide range of installations—from pedestrian areas to light vehicular traffic—while offering easy installation and long-term reliability
TIER
15
Features
- Ideal for medium to high fiber counts, depending on cable type.
- These units can be used for retro fitting (built around / on top of existing network infrastructure) by making use of the port technology and modular panel configuration.
- A smaller lid diameter and tapered body allows for a smaller surface footprint of 20.25” [514mm] with maximized volume in the chamber / vault for cable and closure housing.
- Hinge-less slide-in lid, with bolt down locking technology.
- Branding: Fiber Optic, custom branding available upon request.
Dimensions
- 19" Round
